ROCKFORD FOSGATE T2500-1BDCP
- Description
ROCKFORD FOSGATE
(T2500-1BDCP) POWER 2500 WATT CLASS-BD CONSTANT POWER AMPLIFIER
The Power T2500-1bdCP is a 2,500 Watt mono amplifier featuring Constant Power. The T2500-1bdCP is so flexible and powerful you can use a pair in bdSYNC mode to create one massive amplifier that can deliver a whopping 5 Kilowatts.
The T2500-1bdCP is based on the legendary T2500-1bd amplifier design with a proprietary "Constant Power" configuration that delivers up to 25% more power (Watts) across all impedance loads. The result is a listening experience cleaner, louder and more impressive than ever before. This T2500-1bdCP amplifier pumps out 2,500 watts, easily driving any array of woofers wired to a 1-ohm load. Use two amps in Power-Sync mode for a whopping 5,000 watt power horse!
FEATURES:
- 24dB/octave crossover
- 1/0 AWG power/ground connectors
- MOSFET power supply
- Audiophile grade speaker connections
- Infrasonic filter
- MOSFET output stage
- RCA pass-thru outputs
- PowerSync - allows 2 amplifiers to be "strapped" together
- MasterSync - allows 1 amplifier to control an array of amplifiers
- 0°/180° Phase Switch
- Blue L.E.D. Simulated VU Signal/Power Meters
TECHNOLOGIES:
- CTA-2006 Compliant: Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.
- Class-AD: This technology allows the amplifier to produce more power with less current draw from the vehicle's charging system.
- Constant Power: Constant Power is a patented circuit topology that provides instantaneous delivery of output power over varying impedance loads.
- DSM: DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and lowers operating temperature.
- MEHSA3: MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.
- Balanced Differential Inputs: Differential inputs eliminate noise picked up by signal cables.
- Punch Bass EQ: Onboard equalizer with up to +18dB @ 45Hz.
- Engineered In The USA: These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered this fanatic product. This statement illustrates our commitment to being Designed and Engineered in the U.S.A.
-
TO-247 MOSFETs: (left-OLD | right-NEW)
Rockford Fosgate amps use custom TO-247 MOSFETs. These have 60% more metal tab area for more power capacity, lower impedance and improved heat dissipation over traditional TO-220 MOSFETs found in competitor amps.
SPECIFICATIONS:
- Cta-2006 Compliant:
- Number of Channels: 1
- Total Power (Sum of Rated Power): 2500 Watts RMS
- Rated Power (RMS Continuous Power)
- 1500 Watts x 1 @ 4-Ohm
- 2500 Watts x 1 @ 2-Ohm
- 2500 Watts x 1 @ 1-Ohm
- Two amplifiers in bdSYNC: 5000 Watts x 1 @ 2-Ohm
- Dynamic Power (PVC/PowerCube®)
- 1823 Watts x 1 @ 4-Ohm
- 2940 Watts x 1 @ 2-Ohm
- 2980 Watts x 1 @ 1-Ohm
- Bridgeable: Yes (two amps can be "strapped" together using bd-Sync2 cable to create one monster amplifier)
- Frequency Response: 20Hz to 250Hz +/-0.5dB
- Input Sensitivity: 150 mV to 4 V
- Circuit Topology Class: Class BD
- Efficiency (average)
- 81.9% @ 4-Ohm
- 77.7% @ 2-Ohm
- 64.5% @ 1-Ohm
- Total Harmonic Distortion (THD+Noise)
- 4-Ohm: <1.0%
- 2-Ohm: <1.0%
- 1-Ohm: <1.0%
- Signal Input: 1 RCA pair
- Signal Output: 1 RCA pair
- Tone Controls: Bass: 0dB to +18dB @ 45Hz
- Crossover Controls
- Low-Pass (LP): 35Hz-250Hz @ 24dB/octave Butterworth
- Infrasonic: 12dB/octave Butterworth, -3dB @ 28Hz
- Remote Controls: Optional Remote PEQ (overrides built-in Punch Bass)
- Visual Indicators:
- Power (Blue LED)
- Thermal (Red LED)
- Protect (Yellow LED)
- Output -00dB to +2dB @ 11 steps (Blue LEDs)
- Battery 9VDC to 16VDC @ 11 steps (Blue LEDs)
- Power Wire Gauge: 1/0 AWG
- Power Input Connector: Block
- Speaker Wire Gauge: 8 AWG to 16 AWG
- Speaker Output Connector: Block
- Cooling: Convection
- Heatsink:
- Operating Voltage: 9 - 16 VDC
- Recommended Fuse (not included): 300 A
- Average Current Draw (13.8V Music): 175 A
- Max. Current Draw (13.8V Sinewave): 350 A
- Suggested Alternator: 200 A
- Included In The Box:
- Dimensions (H x W x D): 2.14 x 8.14 x 21.875 (in) 5.44 x 20.68 x 55.66 (cm)
- Shipping Weight: 21.7 Lbs. (9.84 Kg.)
