HERTZ SX 165 NEO

HERTZ

(SX 165 NEO) 6.5" 100W RMS(200W PEAK POWER) 2-WAY COAX NEO MAGNET UV/WATERPROOFING

Totally new NEO SPL coaxial SX 165 NEO cone is made with nature-proof high stiffness pressed-paper featuring innovative water/humidity resistant and anti-UV treatments. The double layer copper voice coil, wound on polyamide former ensures unparalleled power handling. New motors units are made of special Neodymium N38 H to obtain a minimum bulk and increased performance. SX 165 NEO features a large Hi-SPL 1.4” PEI dome tweeter with resettable solid-state protection circuit and a protective rubber gasket for high SPL and a safe outdoor use.

FEATURES:

• Power Handling - Peak W: 200
• Power Handling - Continuous W: 100 Hi-pass filtered @ 150 Hz - 12 dB Oct.
• Impedance Ohms: 4
• Frequency response Hz: 100 ÷ 20k
• Sensitivity dB SPL: 96,5
• Woofer size mm (in.): 165 (6.5)
• Midwoofer size mm (in.) -
• Tweeter size mm (in.): 35 (1.4)
• Supertweeter size mm (in.) -
• Woofer Voice Coil Ø mm (in.): 38 (1.5)
• Tweeter voice coil Ø mm (in.): 28 (1.1)
• Woofer magnet Special Neodymium N38 H
• Midwoofer magnet -
• Tweeter magnet Special Neodymium N38 H
• Woofer cone: Water repellent pressed paper
• Tweeter dome: Pei
• Supertweeter dome -

SPECIFICATIONS:

• Diameter : 6.5 Inch
• Sensitivity : 96.5 dB
• Impedance : 4 Ohm
• Frequency Response : 100-20000 Hz
• RMS Power Output : 100 Watts
• Peak Power Handling : 200 Watts
• RMS Power Handling : 100 Watts
