HERTZ SV 165.1

HERTZ

(SV165.1) 6.5" 400W PEAK POWER HANDLING 4-OHM IMPEDANCE SPL MIDRANGE SPEAKERS (PAIR)

The SV 165.1 car audio midrange can be employed to build systems with tremendous impact. Like the SX subwoofers, the SV 165.1 features a solid, robust structure and, like all the other SPL Show components, it employs a copper voice coil wound on a two-layer KSV former, for unheard-of thermal and mechanical capability also in extreme circumstances. The cone features a water repellent pressed paper membrane and paper dust caps, both robust and light weight, as well as double-wave damped fabric surrounds to ensure linearity even under extreme conditions, contributing to high SPL scores.

FEATURES:

• High magnetic permeability plates provide constant, even flux.
• High density flux ferrite magnet, for top SPL performance.
• Double layer copper voice coil, wound on KSV former; for excellent thermal and mechanical capability.
• High current, tin-plated terminals.
• Damped fabric surround; for maximum lightness and extreme SPL.
• Water-repellent, pressed paper cone

Specifications:

• Size mm (in.): 165 (6.5)

• Power Handling - Peak W: 400

• Impedance: 4 ohms

• Frequency response Hz: 100 ÷ 10k

• Sensitivity dB SPL: 97

• Voice coil Ø mm (in.): 38 (1.5)

• Magnet: High density flux ferrite

• Cone/Dome: Ultra light pressed paper

• Diameter : 6.5 Inch

• Maximum Power : 400 Watts

• Sensitivity : 97 dB

• Impedance : 4 Ohm

• Frequency Response : 100-10000 Hz

• Peak Power Handling : 400 Watts
