HERTZ MPX 165.3

HERTZ

(MPX165.3) MILLE PRO SERIES 6-1/2" 100W RMS (200W PEAK POWER HANDLING) 2-WAY COAXIAL SPEAKERS

 The  coax tweeter concentric to the woofer of the MPX 165.3 car audio coaxial speakers  allows for one single linear-phase emission point, for a natural timbre providing a detailed sound stage. Thanks to the “Center Tuning Duct” geometry, the tweeter resonance frequency is especially low and the employment of damping materials for the inside provides for a linear acoustic emission. The acoustic lens optimizes its off-axis response, which is typical with door installation of coax speakers; besides, the 36 mm diameter woofer generates deep and controlled bass frequencies.

FEATURES:

• CONCENTRIC COAXIAL TWEETER: built in the woofer voice coil, achieving one single point of emission, to re-create the virtual sound-stage like in live music performances.
• TWEETER SUPPORT WORKING AS A REAR CHAMBER: sized for low Fs, to ensure a well damped high pass frequency roll-off, allowing low cut-off frequency crossover point.
• 36 MM PURE COPPER WOOFER VOICE COIL: wound on a Polyamide former, for outstanding power handling and dynamic compression-free reproduction.
• PRESSED-PULP CONE WITH COTTON FIBERS: combining stiffness and lightweight for a wide frequency response. Cone profile geometrically refined to perfectly match with the tweeter emission ensuring phase consistency in the crossover area.
• “BOUNDARY FREE” RUBBER SURROUND: for improved efficiency and wider midbass frequency. (Logo Boundary Free)
• OVER-SIZED FERRITE MAGNET: combined with very low carbon content iron plates, for low distortion at high power levels.
• BASKET: low mounting depth, acoustically transparent aluminium alloy basket with elegant diamond cutting and featuring the aluminium Hertz logo.
•  ANTI-VIBRATION RUBBER MAGNET COVER: to damp spurious vibrations.

SPECIFICATIONS:

• Power Handling - Peak W: 200

• Power Handling - Continuous W: 100

• Impedance: 4 ohms

• Frequency response Hz: 45 ÷ 21,5k

• Sensitivity dB SPL: 92

• Woofer size mm (in.): 165 (6.5)

• Tweeter size mm (in.): 25 (1)

• Woofer Voice Coil Ø mm (in.): 36 (1.42)

• Tweeter voice coil Ø mm (in.): 20 (0.8)

• Woofer magnet: High density flux ferrite

• Tweeter magnet: Neodymium

• Woofer cone: Pressed-pulp cone with cotton fibers

• Tweeter dome: Tetolon

• Diameter : 6.5 Inch

• Sensitivity : 92 dB

• Impedance : 4 Ohm

• Frequency Response : 45-21500 Hz

• Peak Power Handling : 200 Watts

• Design : 2 Way

• Top Mount Depth : 2-9/16 Inches

• RMS Power Handling : 100 Watts
