JL AUDIO MMR-20-BE

JL AUDIO

(MMR-20-BE) ROUND, WIRED, NON-DISPLAY REMOTE CONTROLLER FOR USE WITH MEDIAMASTER®

Round, wired, non-display remote controller for use with MediaMaster®

The MMR-20-BE is a wired remote controller engineered to add auxiliary control functionality to MediaMaster® source units.

Built for marine and off-road applications, its weatherproof (IP67 rated) design places frequently used functions of your MediaMaster® source unit in a simple, intuitive design that’s easy-to-use. Its large, backlit controls and LED source indicators are easily identifiable, day or night, with brightness settings that can be adjusted using your MediaMaster® source unit.

A small footprint and simple, one-hole design means the MMR-20-BE can be installed in even the tightest of spaces. Depending on your system layout, you may add up to three MMR-20-BE remote controllers to a single MediaMaster® source unit. Each MMR-20 can be connected up to 75 ft. (22.8 m) away from its source unit.

MEDIAMASTER® REMOTE CONTROL CAPABILITIES INCLUDE:

• Power On/Off
• Source Select
• Volume Up/Down
• Track Up/Down (USB & BT)
• Track Fast-Forward/Fast-Rewind (USB)
• Favorite Up/Down (Radio)
• Play/Pause (USB & BT)
• Mute/Unmute (Radio & Aux)

THE MMR-20-BE IS COMPATIBLE WITH THESE MEDIAMASTER® SOURCE UNITS:

• MM105
• MM100s-BE
• MM100s
• MM50

Note: Requires MMC Connection Cables (sold separately). Connection cables are available in several lengths to fit your specific application. Y-splitters are also available to connect up to three remotes to a MediaMaster® source unit.

PHYSICAL SPECIFICATIONS:

• Maximum Mounting Panel Thickness : 1.5 in / 38 mm
• Mounting Hole Diameter : 2 in / 50 mm
• Rear Depth (A)* : 1.16 in / 29 mm
• Width (W) : 2.36 in / 60 mm
• Height (H) : 2.36 in / 60 mm
• Depth (D) : 0.59 in / 15 mm

*Total mounting depth is greater (and varies by installation) with mounting bracket.

In-store Purchase only

SKU # 99921
