HERTZ HCP 1MDK

HERTZ

(HCP 1MDK) 2480 PEAK MONOBLOCK CLASS-D MARINE CAR AUDIO AMPLIFIER

HCP 1MDK mono marine amplifier features latest generation D-Class 2Ω stable output stage reaching the impressive RMS power of 740 W x 1 (4 Ω). Engineered and tested for the real environment of application (UV, salt-fog, vibrations, high/low temperature, thermal shock, dust), HCP 1MDK features a compact design built from extruded aluminium heatsink with top side ensuring effective heat transfer. The special balanced input circuitry reject electro-

FEATURES:

• Hertz HCP Series Class D 2 ohms Stable Monoblock Amplifier
• RMS Power Rating:
• 4 ohms: 600 watts x 1 channel
• 2 ohms: 1100 watts x 1 channel
• Total RMS power output: 1240 watts
• Salt Fog Tested
• Water Jet Tested
• LED Power/Protect Light
• Wired remote bass level control included
• Soft start turn-on
• Speaker-level (high-level) inputs
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Input sensitivity:
• Low level : 0.2 - 5 volts
• Frequency Response : 10 - 500 Hz
• Total Harmonic Distortion (THD) : 0.25%
• Signal to Noise Ratio : 100 dB
• Variable low-pass filter : 50 - 250 Hz
• Variable Bass Boost : 0 - 6 dB
• Fuse Rating : 90
• Dimensions : 7.48" W x 1.97" L x 12.40" H
