AUDIO CONTROL DM-RTA

AUDIO CONTROL

(DM-RTA) REAL TIME ANALYZER AND MULTI-TEST TOOL

Building from a legacy of trusted professional audio measurement products, the DM-RTA™ brings the vital tools you rely on to one indispensable interface. Populated with every connector we could think of, and coupled with the new DM-RTA app, AudioControl’s DM-RTA helps you take your car audio, marine audio or home theater installations to new levels of perfection and control.

The DM-RTA connects to a Mac or PC via USB, or to a phone or tablet via Bluetooth using the AC-BT24 Bluetooth Streamer/Programmer (available separately).

PRODUCT HIGHLIGHTS:

• five-in-one signal analyzing tool
• AudioControl's DM-RTA app for PC, Android, or iOS device included
• voltage meter (Vrms)
• real-time analyzer (RTA)
  • 1/3, 1/6, or 1/12 octave resolution
• SPL meter
• polarity checker
• oscilloscope

FEATURES:

• Test and Measure Any Signal
• Balanced Line Level Inputs and Outputs
• Unbalanced Line Level Inputs and Outputs
• Speaker Level Inputs (handles up to 400 watts)
• Microphone Input with 48V Phantom Power (microphone sold separately)
• Microphone presets (for CM-10, CM-20 & C550H)
• Digital and USB Outputs
• Connect to PC/Mac, Phone or Tablet
• Option Port for Bluetooth Connectivity
• Battery Powered and Compact for Portability
• DM-RTA app available in downloads for Mac/PC, or App Store, Google Play
• Dimensions: Approx. 8 x 6 x 2.5 inches
• Weight: 1.9lbs

OTHER FEATURES:

• Inputs: microphone, balanced line, unbalanced line, speaker-level
  • switchable 48V phantom power for mic input
• Onboard test tones with adjustable frequency and output level:
  • sine wave, pink noise, square wave
• Outputs: balanced line, unbalanced line, digital coax, digital optical, USB
• Port for optional AC-BT24 Bluetooth module for wireless monitoring
• Rechargeable battery included
• Mic not included
