JL AUDIO 8W1v3-4

JL AUDIO

(8W1V3-4) 8-INCH SUBWOOFER DRIVER (150W, 4 OHM)

OVERVIEW:

• The 8W1v3 is an outstanding choice when space is very tight and amplifier power is moderate. It features shallow mounting depth (3.86 in. / 98 mm) and a compact motor structure, allowing it to comfortably fit in a lot of spaces where a typical 8-inch driver will not. Lacking a pole vent, the rear of the motor structure can be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow it to reproduce sub-bass with shocking extension and quality. Several of JL Audio's proprietary technologies enhance its performance and reliability.
• The 8W1v3-4 is best used with amplifier power in the 50W - 150W range and is optimized to operate in a compact 0.350 cu. ft. (9.90 l) sealed enclosure. Detailed enclosure recommendations can be found in the "Specifications" tab.

GENERAL SPECIFICATIONS:

• Continuous Power Handling (RMS) : 150 W
• Recommended Amplifier Power (RMS) : 50 - 150 W
• Nominal Impedance (Znom) : 4 Ω

PHYSICAL SPECIFICATIONS:

• Nominal Diameter : 8.0 in / 200 mm
• Overall Diameter (A) : 8.5 in / 216 mm
• Mounting Hole Diameter (B) : 7.09 in / 180 mm
• Bolt Hole Circle Diameter (C) : 7.85 in / 199 mm
• Motor Outer Diameter (D) : 4.72 in / 120 mm
• Mounting Depth (E) : 3.86 in / 98 mm
• Driver Displacement : 0.018 cu ft / 0.51 L
• Net Weight : 7.4 lb / 3.4 kg

PARAMETERS:

• Free Air Resonance (Fs) : 35.40 Hz
• Electrical “Q” (Qes) : 0.451
• Mechanical “Q” (Qms) : 5.791
• Total Speaker “Q” (Qts) : 0.418
• Equivalent Compliance (Vas) : 0.68 cu ft / 19.26 L
• One-Way Linear Excursion (Xmax)* : 0.3 in / 8 mm
• Reference Efficiency (no) : 0.18%
• Efficiency (1 W / 1 m)** : 84.8 dB SPL
• Effective Piston Area (Sd) : 32.67 sq in / 0.0211 sq m
• DC Resistance (Re) : 4.06 Ω

* Xmax specifications are derived via one-way voice coil overhang method with no correction factors applied.
** Efficiency (1 W / 1 m) is not an accurate indicator of a subwoofer’s output capability and should not be used as a comparison to other subwoofers to determine which one is “louder”.

SEALED ENCLOSURE SPECIFICATIONS:

• Wall Thickness : 0.75 in / 19 mm
• Front Baffle Thickness : 0.75 in / 19 m
• Volume (net int.) : 0.350 cu ft / 9.90 L
• External Width (W) : 12 in / 305 mm
• External Height (H) : 10 in / 254 mm
• External Depth (D) : 8.625 in / 219 mm
• F3 : 59.9 Hz
• FC : 60.7 Hz
• Qtc : 0.717

PORTED ENCLOSURE SPECIFICATIONS:

• Wall Thickness : 0.75 in / 19 mm
• Front Baffle Thickness : 0.75 in / 19 mm
• Volume (net int.) : 0.50 cu ft / 14.2 L
• External Width (W) : 13.0 in / 330 mm
• External Height (H) : 10 in / 254 mm
• External Depth (D) : 11.125 in / 283 mm
• Internal Port Diameter (ID) : 2 in / 51 mm
• Port Length (L) : 10 in / 254 mm
• Tuning Frequency (Fb) : 38 Hz
• F3 : 39.10 Hz
